Find the velocity and rate of flow of water through a rectangular channel of 6m wide and 3m deep when it's running full. The cha

nnel is having a bed slope of 1 in 2000. Take Chezy's coefficient, C=55

1 answer:

Elza [17]2 years ago

5 0

Answer:

V = 1.5062 m/s

Explanation:

look to the photos

You might be interested in

A shipment of rebar that weighs 745 kg would weigh roughly how much in pounds

Andre45 [30]

Answer:

Dont no but will check

Explanation:

6 0

2 years ago

Your task is to fill in the missing parts of the C code to get a program equivalent to the generated assembly code. Recall that

Rudik [331]

Answer:

See Explaination

Explanation:

//Function

long loop (long x, long n)

{

//Declare a variable named result and initialize it to zero

long result = 0;

//Declare a variable named mask

long mask;

//For loop

for(mask = 1; mask != 0; mask = mask << (n & 0xFF))

{

//Calculate

result | = (x&mask);

}

//Return result

return result;

}

6 0

2 years ago

Hot exhaust gases of an internal combustion engine are to be used to produce saturated water vapor at 2 MPa pressure. The exhaus

Anastaziya [24]

Answer:

The flowrate of water is 0.03556kg/s

Explanation:

Exhaust gases inlet temperature T1=4000C

Water inlet temperature T3=150C Exit Pressure of water as saturated vapor P4=2MPa

Mass flow rate of exhaust gases Heat lost to the surroundings Qgases=32kg/min

Mass flow rate of exhaust gases is 15 times that of the water

Heat exchangers typically involve no work interactions (w = 0) and negligible...

7 0

2 years ago

Read 2 more answers

Sharon is designing a house in an area that receives a lot of rainfall all year. Which material should she use to stick the wood

kakasveta [241]

Explanation:

She is passionate about architecture, typography, and black & white film ... Since moving to Texas, I've heard a lot of people say, "If you don't like ... Oc, 3.74, 56, 80 ... Not only does the weather have to be clear to pour the concrete, but it ... system that goes within the slab) is complete, any additional rain will

4 0

2 years ago

The wires each have a diameter of 12 mm, length of 0.6 m, and are made from 304 stainless steel. Determine the magnitude of forc

Sonbull [250]

Answer:

Magnitude of force P = 25715.1517 N

Explanation:

Given - The wires each have a diameter of 12 mm, length of 0.6 m, and are made from 304 stainless steel.

To find - Determine the magnitude of force P so that the rigid beam tilts 0.015∘.

Proof -

Given that,

Diameter = 12 mm = 0.012 m

Length = 0.6 m

$\theta$ = 0.015°

Youngs modulus of elasticity of 34 stainless steel is 193 GPa

Now,

By applying the conditions of equilibrium, we have

∑fₓ = 0, ∑ $f_{y}$ = 0, ∑M = 0

If ∑ $M_{A}$ = 0

⇒ $F_{BC}$ ×0.9 - P × 0.6 = 0

⇒ $F_{BC}$ ×3 - P × 2 = 0

⇒ $F_{BC}$ = $\frac{2P}{3}$

If ∑ $M_{B}$ = 0

⇒ $F_{AD}$ ×0.9 = P × 0.3

⇒ $F_{AD}$ ×3 = P

⇒ $F_{AD}$ = $\frac{P}{3}$

Now,

Area, A = $\frac{\pi }{4} X (0.012)^{2}$ = 1.3097 × 10⁻⁴ m²

We know that,

Change in Length , $\delta$ = $\frac{P l}{A E}$

Now,

$\delta_{AD} = \frac{P(0.6)}{3(1.3097)(10^{-4}) (193)(10^{9} }$ = 9.1626 × 10⁻⁹ P

$\delta_{BC} = \frac{2P(0.6)}{3(1.3097)(10^{-4}) (193)(10^{9} }$ = 1.83253 × 10⁻⁸ P

Given that,

$\theta$ = 0.015°

⇒ $\theta$ = 2.618 × 10⁻⁴ rad

So,

$\theta = \frac{\delta_{BC} - \delta_{AD}}{0.9}$

⇒2.618 × 10⁻⁴ = ( 1.83253 × 10⁻⁸ P - 9.1626 × 10⁻⁹ P) / 0.9

⇒P = 25715.1517 N

∴ we get

Magnitude of force P = 25715.1517 N

6 0

2 years ago
