(20pts) Air T[infinity] = 10 °C and u[infinity] = 100 m/s flows over a flat plate. Assume that the density of air is 1.0 kg/m3 a
nd the dynamics viscosity is 1.8 ×10-6 kg/m∙s. (a) Determine the velocity boundary layer thickness at, δ at x = 2 m (x indicates the distance from the leading edge of the plate). (b) Determine local friction coefficient at x = 2 m. (c) Determine the Nusselt number at x = 2 m. Assume that the velocity boundary layer thickness is the same as the thermal boundary layer thickness (δ = δT).
1 answer:
You might be interested in
Answer:
a)σ₁ = 265.2 MPa
b)σ₂ = -172.8 MPa
c)
d)Range = 438 MPa
Explanation:
Given that
Mean stress ,σm= 46.2 MPa
Stress amplitude ,σa= 219 MPa
Lets take
Maximum stress level = σ₁
Minimum stress level =σ₂
The mean stress given as
2 x 46.2 = σ₁ + σ₂
σ₁ + σ₂ = 92.4 MPa --------1
The amplitude stress given as
2 x 219 = σ₁ - σ₂
σ₁ - σ₂ = 438 MPa --------2
By adding the above equation
2 σ₁ = 530.4
σ₁ = 265.2 MPa
-σ₂ = 438 -265.2 MPa
σ₂ = -172.8 MPa
Stress ratio
Range = 265.2 MPa - ( -172.8 MPa)
Range = 438 MPa
