An equation used to evaluate vacuum filtration is Q = ΔpA2 α(VRw + ARf) , Where Q ≐ L3/T is the filtrate volume flow rate, Δp ≐

F/L2 the vacuum pressure differential, A ≐ L2 the filter area, α the filtrate "viscosity," V ≐ L3 the filtrate volume, R ≐ L/F the sludge specific resistance, w ≐ F/L3 the weight of dry sludge per unit volume of filtrate, and Rf the specific resistance of the filter medium. What are the dimensions of Rf and and α?

1 answer:

larisa86 [58]2 years ago

6 0

Answer:

Explanation:

The explanations and answers are shown in the following attachments

You might be interested in

a. (24 points) Describe the microstructure present in a 10110 steel after each step in each of the following heat treatments (no

Mrac [35]

Answer:

Explanation:

Please check the below file for the attached file

6 0

2 years ago

Problem 5) Water is pumped through a 60 m long, 0.3 m diameter pipe from a lower reservoir to a higher reservoir whose surface i

kap26 [50]

Answer:

\epsilon = 0.028*0.3 = 0.0084

Explanation:

\frac{P_1}{\rho} + \frac{v_1^2}{2g} +z_1 +h_p - h_l =\frac{P_2}{\rho} + \frac{v_2^2}{2g} +z_2

where P_1 = P_2 = 0

V1 AND V2 =0

Z1 =0

h_P = \frac{w_p}{\rho Q}

=\frac{40}{9.8*10^3*0.2} = 20.4 m

20.4 - (f [\frac{l}{d}] +kl) \frac{v_1^2}{2g} = 10

we know thaTV =\frac{Q}{A}

V = \frac{0.2}{\pi \frac{0.3^2}{4}} =2.82 m/sec

20.4 - (f \frac{60}{0.3} +14.5) \frac{2.82^2}{2*9.81} = 10

f = 0.0560

Re =\frac{\rho v D}{\mu}

Re =\frac{10^2*2.82*0.3}{1.12*10^{-3}} =7.53*10^5

fro Re = 7.53*10^5 and f = 0.0560

\frac{\epsilon}{D] = 0.028

\epsilon = 0.028*0.3 = 0.0084

4 0

2 years ago

. A cylindrical metal specimen having an original diameter of 12.8 mm (0.505 in.) and gauge length of 50.80 mm (2.000 in.) is pu

kogti [31]

Answer:

% reduction in area==PR=0.734=73.4%

% elongation=EL=0.42=42%

Explanation:

given do=12.8 mm

df=6.60

Lf=72.4 mm

Lo=50.8 mm

% reduction in area=(( $\pi$ *(do/2)^2)-( $\pi$ *(df/2)^2)))/ $\pi$ *(do/2)^2

substitute values

% reduction in area=73.4%

% elongation=EL=((Lf-Lo)/Lo))*100

% elongation=((72.4-50. 8)/50.8)*100=42%

6 0

2 years ago

A 20 dBm power source is connected to the input of a directional coupler having a coupling factor of 20 dB, a directivity of 35

lukranit [14]

Answer:

$P_O = 0.989 watt = 19.9 dBm$

Explanation:

Given data:

P_1 power = 20 dBm = 0.1 watt

coupling factor is 20dB

Directivity = 35 dB

We know that

coupling factor $= 10 log \frac{P_1}{P_f}$

solving for final power

$20 = 10 log\frac{P_1}{P_f}$

$2 = log \frac{P_1}{P_f}$

$100 = \frac{0.1}{P_f}$

$P_f = 0.001 watt = 0 dBm$

Directivity $D = 10 \frac{P_f}{P_b}$

$35 = 10 \frac{0.001}{P_b}$

$P_b = 3.162 \times 10^{-7} wattt$

output Power $= P_1 -P_f - P_b$

$= 0.1 - 0.001 - 3.162 \times 10^{-7}$

$P_O = 0.989 watt = 19.9 dBm$

6 0

2 years ago

Methane and oxygen react in the presence of a catalyst to form formaldehyde. In a parallel reaction, methane is oxidized to carb

Nezavi [6.7K]

Answer:

$y_{CH_4}^2=\frac{5mol/s}{100mol/s}=0.05\\y_{O_2}^2=\frac{3mol/s}{100mol/s}=0.03\\y_{H_2O}^2=\frac{47mol/s}{100mol/s}=0.47\\y_{HCHO}^2=\frac{43mol/s}{100mol/s}=0.43\\y_{CO_2}^2=\frac{2mol/s}{100mol/s}=0.02$

Explanation:

Hello,

a. On the attached document, you can see a brief scheme of the process. Thus, to know the degrees of freedom, we state the following unknowns:

- $\xi_1$ and $\xi_2$ : extent of the reactions (2).

- $F_{O_2}^2$ , $F_{CH_4}^2$ , $F_{H_2O}^2$ , $F_{HCHO}^2$ and $F_{CO_2}^2$ : Molar flows at the second stream (5).

On the other hand, we've got the following equations:

- $F_{O_2}^2=50mol/s-\xi_1-2\xi_2$ : oxygen mole balance.

- $F_{CH_4}^2=50mol/s-\xi_1-\xi_2$ : methane mole balance.

- $F_{H_2O}^2=\xi_1+2\xi_2$ : water mole balance.

- $F_{HCHO}^2=\xi_1$ : formaldehyde mole balance.

- $F_{CO_2}^2=\xi_2$ : carbon dioxide mole balance.

Thus, the degrees of freedom are:

$DF=7unknowns-5equations=2$

It means that we need two additional equations or data to solve the problem.

b. Here, the two missing data are given. For the fractional conversion of methane, we define:

$0.900=\frac{\xi_1+\xi_2}{50mol/s}$

And for the fractional yield of formaldehyde we can set it in terms of methane as the reagents are equimolar:

$0.860=\frac{F_{HCHO}^2}{50mol/s}$

In such a way, one realizes that the output formaldehyde's molar flow is:

$F_{HCHO}^2=0.860*50mol/s=43mol/s$

Which is equal to the first reaction extent $\xi_1$ , therefore, one computes the second one from the fractional conversion of methane as:

$\xi_2=0.900*50mol/s-\xi_1\\\xi_2=0.900*50mol/s-43mol/s\\\xi_2=2mol/s$

Now, one computes the rest of the output flows via:

- $F_{O_2}^2=50mol/s-43mol/s-2*2mol/s=3mol/s$

- $F_{CH_4}^2=50mol/s-43mol/s-2mol/s=5mol/s$

- $F_{H_2O}^2=43mol/s+2*2mol/s=47mol/s$

- $F_{HCHO}^2=43mol/s$

- $F_{CO_2}^2=2mol/s$

The total output molar flow is:

$F_{O_2}+F_{CH_4}+F_{H_2O}+F_{HCHO}+F_{CO_2}=100mol/s$

Therefore the output stream composition turns out into:

$y_{CH_4}^2=\frac{5mol/s}{100mol/s}=0.05\\y_{O_2}^2=\frac{3mol/s}{100mol/s}=0.03\\y_{H_2O}^2=\frac{47mol/s}{100mol/s}=0.47\\y_{HCHO}^2=\frac{43mol/s}{100mol/s}=0.43\\y_{CO_2}^2=\frac{2mol/s}{100mol/s}=0.02$

Best regards.
