For flow of a liquid metal through a circular tube, the velocity and temperature profiles at a particular axial location may be
approximated as being uniform and parabolic, respectively. That is, u(r) = C, and TO-T, = C11-(r/ro)2], where Ci and C2 are constants. what is the value of the Nusselt number Nup at this location?
1 answer:
Answer:
Nup = 8
Explanation:
u(r) = C1 and T(r) = T(s) = C2 [ 1 - r/ro)^2 ]
The temperature and velocity particles at a particular axial location is Uniform and parabolic
The Nusset Number Nup at this location can be obtained by first determining/calculating for the convection coefficient =
Therefore the mean temperature is calculated as follows
attached is the detailed solution and free body diagram
