Answer:
21.6 kw
Explanation:
Given data:
m = 50 kg/s
Inlet pressure (p1) = 2 bar
outlet pressure(p2) = 6.2 bar
suction ( h1 ) = -2.2 m
delivery ( h2 ) = 8.5 m
d1 = 200 mm = 0.2 m
d2 = 100 mm = 0.1 m
Vs of water = 0.001 m^3/kg
next we have to determine the Q value
Q = V*A
Q = 0.001 * 50 = 0.05 m^3/s
next we have to calculate the various V's
V1 = Q/A1 = = 1.59 m/s
V2 = Q/A2 = = 6.37 m/s
Determine the capacity of the electric motor
attached below is the detailed solution
Answer:
a)Wt =25.68 lbf
b)Wt = 150 lbf
F= 899.59 N
Explanation:
Given that
m= 150 lbm
a)
Weight on the spring scale(Wt) = m g
We know that
Wt = 150 x 5.48/32 lbf
Wt =25.68 lbf
b)
On the beam scale
This is scale which does not affects by gravitational acceleration.So the wight on the beam scale will be 150 lbf.
Wt = 150 lbf
If the plane is moving upward with acceleration 6 g's then the for F
F = m a
We know that
a=6 g's
So
F = 90 x 9.99 N
F= 899.59 N
Answer:
Ps=19.62N
Explanation:
The detailed explanation of answer is given in attached files.
Answer:
For aluminum 110.53 C
For copper 110.32 C
Explanation:
Heat transmission through a plate (considering it as an infinite plate, as in omitting the effects at the borders) follows this equation:
Where
q: heat transferred
k: conduction coeficient
A: surface area
th: hot temperature
tc: cold temperature
d: thickness of the plate
Rearranging the terms:
d * q = k * A * (th - tc)
The surface area is:
If the pan is aluminum:
If the pan is copper:
