Why a brass lid ring on a glass canning jar will loosen when heated.

Engineering

1 answer:

Zolol [24]1 year ago

4 0

hi here is your answer hope it helps or then sry

Explanation:

A brass lid on a glass canning jar will loosen when heated because brasshas the greater coefficient of thermal expansion

You might be interested in

An annealed copper strip of 228 mm wide and 25 mm thick being rolled to a thickness of 20 mm, in one pass. The roll radius is 30

sdas [7]

Answer:

The roll force is 1.59 MN

The power required in this operation is 644.96 kW

Explanation:

Given;

width of the annealed copper, w = 228 m

thickness of the copper, h₀ = 25 mm

final thickness, hf = 20 mm

roll radius, R = 300 mm

The roll force is given by;

$F = LwY_{avg}$

where;

w is the width of the annealed copper

$Y_{avg}$ is average true stress of the strip in the roll gap

L is length of arc in contact, and for frictionless situation it is given as;

$L = \sqrt{R(h_o-h_f)} \\\\L = \sqrt{300(25-20)}\\\\L = 38.73 \ mm$

Now, determine the average true stress, $Y_{avg}$ , for the annealed copper;

The absolute value of the true strain, ε = ln(25/20)

ε = 0.223

from true stress vs true strain graph; at true strain of 0.223, the true stress is 280 MPa.

Then, the average true stress = ¹/₂(280 MPa.) = 180 MPa

Finally determine the roll force;

$F = LwY_{avg}$

$F = (\frac{38.73 }{1000})(\frac{228}{1000})*180 \ MPa\\\\F = 1.59 \ MN$

The power required in this operation is given by;

$P = \frac{2\pi FLN}{60}\\\\P = \frac{2\pi (1.59*10^6)(0.03873)(100)}{60}\\\\P = 644955.2 \ W\\\\P = 644.96 \ kW$

5 0

2 years ago

5. Which of these materials in a shop contain metals and toxins and can pollute the environment? A) Antifreeze B) Solvents C) Ba

Elza [17]

As a multiple choice the only correct answer is D

3 0

2 years ago

Read 2 more answers

A person puts a few apples into the freezer at -15oC to cool them quickly for guests who are about to arrive. Initially, the app

frosja888 [35]

Answer:

Temperature at center of apples = 11.2⁰C

Temperature at surface of apples = 2.7⁰C

Amount of Heat transferred = 17.2kJ

Explanation:

The properties of apple are given as:

k = 0.418 W/m.°C

ρ = 840 kg/m³

Cр = 3.81 kJ/kg.°C

α = 1.3*10 ⁻⁷ m²/s

h = 8 W/m².°C

d = 0.09m

r = 0.045m

t = 1 hour = 3600s

<h2>Solution</h2>

Biot number is given as:

$Bi = \frac{hr}{k}= \frac{8\cdot0.045}{0.418}=0.861$

The constants λ₁ and A₁ corresponding to Biot number (from the table) are:

λ₁ = 1.476

A₁ = 1.239

Fourier Number is:

$T = \frac{a\cdot{t}}{r^2} = \frac{(1.3\cdot10^{-7})(3600)}{0.045^2}= 0.231> 0.2$

As Fourier Number > 0.2 , one term approximates solutions are applicable

The temperature at the center of apples, The temperature at surface of apples and Amount of heat transfer is found in the ATTACHMENT.

8 0

2 years ago

Water is flowing in a metal pipe. The pipe OD (outside diameter) is 61 cm. The pipe length is 120 m. The pipe wall thickness is

Yuki888 [10]

Answer:

1113kN

Explanation:

The ouside diameter OD of the pipe is 61cm and the thickness T is 0.9cm, so the inside diameter ID will be:

Inside Diameter = Outside Diameter - Thickness

Inside Diameter = 61cm - 0.9cm = 60.1cm

Converting this diameter to meters, we have:

$60.1cm*\frac{1m}{100cm}=0.601m$

This inside diameter is useful to calculate the volume V of water inside the pipe, that is the volume of a cylinder:

$V_{water}=\pi r^{2}h$

$V_{water}=\pi (\frac{0.601m}{2})^{2}*120m$

$V_{water}=113.28m^{3}$

The problem gives you the water density d as 1.0kg/L, but we need to convert it to proper units, so:

$d_{water}=1.0\frac{Kg}{L}*\frac{1L}{1000cm^{3}}*(\frac{100cm}{1m})^{3}$

$d_{water}=1000\frac{Kg}{m^{3}}$

Now, water density is given by the equation $d=\frac{m}{V}$ , where m is the water mass and V is the water volume. Solving the equation for water mass and replacing the values we have:

$m_{water}=d_{water}.V_{water}$

$m_{water}=1000\frac{Kg}{mx^{3}}*113.28m^{3}$

$m_{water}=113280Kg$

With the water mass we can find the weight of water:

$w_{water}=m_{water} *g$

$w_{water}=113280kg*9.8\frac{m}{s^{2}}$

$w_{water}=1110144N$

Finally we find the total weight add up the weight of the water and the weight of the pipe,so:

$w_{total}=w_{water}+w_{pipe}$

$w_{total}=1110144N+2500N$

$w_{total}=1112644N$

Converting this total weight to kN, we have:

$1112644N*\frac{0.001kN}{1N}=1113kN$

7 0

2 years ago

Technician A that shielding gas nozzles may have different shapes. Technician B says that gelding gas nozzles is attached to the

Lilit [14]

B is correct! in this senecio
