Answer:
A) x _electron = 0.66 10² m
, B) x _Eart = 1.13 10² m
, C) d_sphere = 1.37 10⁻² mm
Explanation:
A) Let's use a ball for the nucleus, the electron is at a farther distance the sphere for the electron must be at a distance of
Let's use proportions rule
x_ electron = 0.529 10⁻¹⁰ /1.2 10⁻¹⁵ 1.5
x _electron = 0.66 10⁵ mm = 0.66 10² m
B) the radii of the Earth and the sun are
= 6.37 10⁶ m
tex]R_{Sum}[/tex] = 6.96 10⁸ m
Distance = 1.5 10¹¹ m
x_Earth = 1.5 10¹¹ / 6.96 10⁸ 1.5
x _Eart = 1.13 10² m
C) The radius of a sphere that represents the earth, if the sphere that represents the sun is 1.5 mm, let's use another rule of proportions
d_sphere = 1.5 / 6.96 10⁸ 6.37 10⁶
d_sphere = 1.37 10⁻² mm
Answer:
35mA
Explanation:
Hello!
To solve this problem we must use the following steps
1. Find the electrical resistance of the metal rod using the following equation

WHERE
α=
metal rod resistivity=2x10^-4 Ωm
l=leght=2m
A= Cross-sectional area

solving

2. Now we model the system as a circuit with parallel resistors, where we will call 1 the metal rod and 2 the man(see attached image)
3.we know that the sum of the currents in 1 and 2 must be equal to 5A, by the law of conservation of energy
I1+I2=5
4.as the voltage on both nodes is the same we can use ohm's law in resitance 1 and 2 (V=IR)
V1=V2
(0.14I1)=2000(i2)
solving for i1
I1=14285.7i2
5.Now we use the equation found in step 3
14285.7i2+i2=5

Answer:
a = 5.05 x 10¹⁴ m/s²
Explanation:
Consider the motion along the horizontal direction
= velocity along the horizontal direction = 3.0 x 10⁶ m/s
t = time of travel
X = horizontal distance traveled = 11 cm = 0.11 m
Time of travel can be given as

inserting the values
t = 0.11/(3.0 x 10⁶)
t = 3.67 x 10⁻⁸ sec
Consider the motion along the vertical direction
Y = vertical distance traveled = 34 cm = 0.34 m
a = acceleration = ?
t = time of travel = 3.67 x 10⁻⁸ sec
= initial velocity along the vertical direction = 0 m/s
Using the kinematics equation
Y =
t + (0.5) a t²
0.34 = (0) (3.67 x 10⁻⁸) + (0.5) a (3.67 x 10⁻⁸)²
a = 5.05 x 10¹⁴ m/s²
Answer:
halve the slit separation
Explanation:
As we know that
In YDS experiment, the equation of fringe width is as follows

where,
D denotes the separation in the middle of screen and slits
d denotes the distance in the middle of two slits
And to increase the Δx we have to decrease the d i.e, the distance between the two slits
Hence, the first option is correct
Electric field strength = resistivity of copper x current density
where
p= 1.72 x 10^-8 <span>ohm meter
diameter = 2.05mm=.00205 m
current = 2.75 A
</span>get first the current density:
current density = current/ cross section area
find the cross section area
cross section area = pi.(d/2)^2;
cross section = 3.3 006x10-6 m^2
substitute the values
current density = 2.75A/3.3006x 10-6m^2
current density=35.55 x1 0^2 A/m^2
Electric field stregnth =1.72 x 10^-8 ohm meter x 35.55 x10^2 A/m^2
Electric field stregnth= 46.415 Volts/m
The electric field strength of copper is 46.415 V/m.
