What is the final temperature after compression of a diesel cycle if the initial temperature is 32C and clearance is 8%

Determine the design angle ϕ (0∘≤ϕ≤90 ∘) between struts AB and AC so that the 400 lb horizontal force has a component of 600 lb

Svetllana [295]

Answer:

design angle ∅ = 4.9968 ≈ 5⁰

Explanation:

First calculate the force Fac :

Fac = $\sqrt{400^2 + 650^2 - 2(400)(650)cos30}$

= $\sqrt{160000 + 422500 - 80210}$

= 708.72 Ib

using the sine law to determine the design angle

$\frac{sin}{400} = \frac{sin 30}{Fac}$

hence ∅ = $sin^{-1} (\frac{sin 30 *400}{708.72} )$

= $sin^{-1} 0.0871$ = 4.9968 ≈ 5⁰

4 0

2 years ago

g The function below takes a single string parameter: sentence. Complete the function to return everything but the middle 10 cha

ale4655 [162]

Answer:

def processString(sentence):
middle = len(sentence) // 2
output = sentence[0: middle - 5] + sentence[middle+5:]
return output
print(processString("I have a dream"))

Explanation:

Create a function processString that take sentence as input paratemer (Line 1).

Next create a variable middle to hold the value of middle index of sentence string (Line 2)

Build the output string by slicing the input sentence from first character to character middle - 5th and from middle + 5th till the end of the string (Line 3).

Test the function using a sample sentence and we shall get the output "I am"

4 0

2 years ago

A railcar with an overall mass of 78,000 kg traveling with a speed vi is approaching a barrier equipped with a bumper consisting

sergij07 [2.7K]

Answer:

v₀ = 2,562 m / s = 9.2 km/h

Explanation:

To solve this problem let's use Newton's second law

F = m a = m dv / dt = m dv / dx dx / dt = m dv / dx v

F dx = m v dv

We replace and integrate

-β ∫ x³ dx = m ∫ v dv

β x⁴/ 4 = m v² / 2

We evaluate between the lower (initial) integration limits v = v₀, x = 0 and upper limit v = 0 x = x_max

-β (0- x_max⁴) / 4 = ½ m (v₀²2 - 0)

x_max⁴ = 2 m /β v₀²

Let's look for the speed that the train can have for maximum compression

x_max = 20 cm = 0.20 m

v₀ =√(β/2m) x_max²

Let's calculate

v₀ = √(640 106/2 7.8 104) 0.20²

v₀ = 64.05 0.04

v₀ = 2,562 m / s

v₀ = 2,562 m / s (1lm / 1000m) (3600s / 1h)

v₀ = 9.2 km / h

5 0

2 years ago

The air contained in a room loses heat to the surroundings at a rate of 50 kJ/min while work is supplied to the room by computer

Artemon [7]

Answer:

net amount of energy change of the air in the room during a 30-min period = 660KJ

Explanation:

The detailed calculation is as shown in the attached file.

4 0

2 years ago

Read 2 more answers

At an impaired driver checkpoint, the time required to conduct the impairment test varies (according to an exponential distribut

professor190 [17]

Answer:

Option (d) 2 min/veh

Explanation:

Data provided in the question:

Average time required = 60 seconds

Therefore,

The maximum capacity that can be accommodated on the system, μ = 60 veh/hr

Average Arrival rate, λ = 30 vehicles per hour

Now,

The average time spent by the vehicle is given as

⇒ $\frac{1}{\mu(1-\frac{\lambda}{\mu})}$

thus,

on substituting the respective values, we get

Average time spent by the vehicle = $\frac{1}{60(1-\frac{30}{60})}$

or

Average time spent by the vehicle = $\frac{1}{60(1-0.5)}$

or

Average time spent by the vehicle = $\frac{1}{60(0.5)}$

or

Average time spent by the vehicle = $\frac{1}{30}$ hr/veh

or

Average time spent by the vehicle = $\frac{1}{30}\times60$ min/veh

[ 1 hour = 60 minutes]

thus,

Average time spent by the vehicle = 2 min/veh

Hence,

Option (d) 2 min/veh

7 0

2 years ago
