Education is an ongoing process in every field. a. True b. False

Engineering

1 answer:

enyata [817]2 years ago

5 0

Answer:

True

Explanation:

Education is the discipline that has to do with the process of enabling learning, (teaching) and knowledge acquisition (learning) of values, habits, skills and values within an academic environment. Some of the techniques of educating people are through narration of stories, formal training, discussion, and instructional guidance

Learning, which is an aspect of education is a continuous process throughout life as it is what we learn we become and therefore, our aspirations depends on our education.

You might be interested in

If you have power steering and you are able to __________, you should have your vehicle checked out by a qualified technician.

svp [43]

Answer: drive

Explanation:

The best word that would fit this sentence is drive. A vehicle owner should know how to drive, and they can get their vehicle checked by a qualified technician. The best word that would fit this sentence is drive. If you have power steering and you are able to <u>drive</u>, you should have your vehicle checked by a qualified technician.

8 0

2 years ago

A three-point bending test was performed on an aluminum oxide specimen having a circular cross section of radius 3.5 mm (0.14 in

RideAnS [48]

To resolve this problem we have,

$R=3.5mm\\F_f1=950N\\L_1=50mm\\b=12mm\\L_2=40mm$

$F_{f2}$ is unknown.

With these dates we can calculate the Flexural strenght of the specimen,

$\sigma{fs}=\frac{F_{f1}L}{\pi R^3}\\\sigma{fs}=\frac{(950)(50*10^{-3})}{\pi 3.5*10^{-3}}\\\sigma{fs}=352.65Mpa$

After that, we can calculate the flexural strenght for the square cross section using the previously value.

$\sigma{fs}=\frac{F_{f2}L}{\pi R^3}\\(352.65*10^6)=\frac{3Ff(40*10^{-3})}{2(12*10^{-10})}\\F_{f2}=\frac{352.65*10^6}{34722.22}\\F_{f2}=10156.32N\\F_{f2}=10.2kN$

6 0

2 years ago

An electric field is expressed in rectangular coordinates by E = 6x2ax + 6y ay +4az V/m.Find:a) VMN if point M and N are specifi

Fittoniya [83]

Answer:

a.) -147V

b.) -120V

c.) 51V

Explanation:

a.) Equation for potential difference is the integral of the electrical field from a to b for the voltage V_ba = V(b)-V(a).

b.) The problem becomes easier to solve if you draw out the circuit. Since potential at Q is 0, then Q is at ground. So voltage across V_MQ is the same as potential at V_M.

c.) Same process as part b. Draw out the circuit and you'll see that the potential a point V_N is the same as the voltage across V_NP added with the 2V from the other box.

Honestly, these things take practice to get used to. It's really hard to explain this.

3 0

2 years ago

. A piston-cylinder device whose piston is resting on top of a set of stops initially contains 0.5 kg of helium gas at 100 kPa a

Delvig [45]

Answer:

Qin = 1857 kJ

Explanation:

Given

m = 0.5 Kg

T₁ = 25°C = (25 + 273) K = 298 K

P₁ = 100 kPa

P₂ = 500 kPa

First, the temperature when the piston starts rising is determined from the ideal gas equations at the initial state and at that state:

T₂ = T₁*P₂/P₁

⇒ T₂ = 298 K*(500 kPa/100 kPa) = 1490 K

Until the piston starts rising no work is done so the heat transfer is the change in internal energy

Qin = ΔU = m*cv*(T₂-T₁)

⇒ Qin = 0.5*3.1156*(1490 - 298) kJ = 1857 kJ

8 0

2 years ago

A thermal energy storage unit consists of a large rectangular channel, which is well insulated on its outer surface and encloses

yaroslaw [1]

Answer:

the temperature of the aluminum at this time is 456.25° C

Explanation:

Given that:

width w of the aluminium slab = 0.05 m

the initial temperature $T_1$ = 25° C

$T{\infty} =600^0C$

h = 100 W/m²

The properties of Aluminium at temperature of 600° C by considering the conditions for which the storage unit is charged; we have ;

density ρ = 2702 kg/m³

thermal conductivity k = 231 W/m.K

Specific heat c = 1033 J/Kg.K

Let's first find the Biot Number Bi which can be expressed by the equation:

$Bi = \dfrac{hL_c}{k} \\ \\ Bi = \dfrac{h \dfrac{w}{2}}{k}$

$Bi = \dfrac{hL_c}{k} \\ \\ Bi = \dfrac{100 \times \dfrac{0.05}{2}}{231}$

$Bi = \dfrac{2.5}{231}$

Bi = 0.0108

The time constant value $\tau_t$ is :

$\tau_t = \dfrac{pL_cc}{h} \\ \\ \tau_t = \dfrac{p \dfrac{w}{2}c}{h}$

$\tau_t = \dfrac{2702* \dfrac{0.05}{2}*1033}{100}$

$\tau_t = \dfrac{2702* 0.025*1033}{100}$

$\tau_t = 697.79$

Considering Lumped capacitance analysis since value for Bi is less than 1

Then;

$Q= (pVc)\theta_1 [1-e^{\dfrac {-t}{ \tau_1}}]$

where;

$Q = -\Delta E _{st}$ which correlates with the change in the internal energy of the solid.

So;

$Q= (pVc)\theta_1 [1-e^{\dfrac {-t}{ \tau_1}}]= -\Delta E _{st}$

The maximum value for the change in the internal energy of the solid is :

$(pVc)\theta_1 = -\Delta E _{st}max$

By equating the two previous equation together ; we have:

$\dfrac{-\Delta E _{st}}{\Delta E _{st}{max}}= \dfrac{ (pVc)\theta_1 [1-e^{\dfrac {-t}{ \tau_1}}]} { (pVc)\theta_1}$

Similarly; we need to understand that the ratio of the energy storage to the maximum possible energy storage = 0.75

Thus;

$0.75= [1-e^{\dfrac {-t}{ \tau_1}}]}$

So;

$0.75= [1-e^{\dfrac {-t}{ 697.79}}]}$

$1-0.75= [e^{\dfrac {-t}{ 697.79}}]}$

$0.25 = e^{\dfrac {-t}{ 697.79}}$

$In(0.25) = {\dfrac {-t}{ 697.79}}$

$-1.386294361= \dfrac{-t}{697.79}$

t = 1.386294361 × 697.79

t = 967.34 s

Finally; the temperature of Aluminium is determined as follows;

$\dfrac{T - T _{\infty}}{T_1-T_{\infty}}= e ^ {\dfrac{-t}{\tau_t}}$

$\dfrac{T - 600}{25-600}= e ^ {\dfrac{-967.34}{697.79}$

$\dfrac{T - 600}{25-600}= 0.25$

$\dfrac{T - 600}{-575}= 0.25$

T - 600 = -575 × 0.25

T - 600 = -143.75

T = -143.75 + 600

T = 456.25° C

Hence; the temperature of the aluminum at this time is 456.25° C

3 0
