A car of mass 300kg starts from rest and travels upwards along a straight road of 450m inclined at an angle of 5 degree to the h

orizontal and the speed of the car is 28m/s at the top of the slope. Determine its acceleration, the time taken to travel, the length of the slope, gain in kinetic energy and gain in gravitational potential energy

1 answer:

zhuklara [117]2 years ago

3 0

Answer:

Look at the picture.

Explanation:

I solved all of questions except the length of the slope because I don't know about it.

You might be interested in

What is the atomic number z of 73li?

aev [14]

I think thats a trick question on the periodic table there is no Z, theres Zi which is zinc but no Z

3 0

2 years ago

Read 2 more answers

A block weighing 400 kg rests on a horizontal surface and supports on top of it ,another block of weight 100 kg which is attache

Paladinen [302]

Answer:

$F_a=1470\ N$

Explanation:

<u>Friction Force</u>

When objects are in contact with other objects or rough surfaces, the friction forces appear when we try to move them with respect to each other. The friction forces always have a direction opposite to the intended motion, i.e. if the object is pushed to the right, the friction force is exerted to the left.

There are two blocks, one of 400 kg on a horizontal surface and other of 100 kg on top of it tied to a vertical wall by a string. If we try to push the first block, it will not move freely, because two friction forces appear: one exerted by the surface and the other exerted by the contact between both blocks. Let's call them Fr1 and Fr2 respectively. The block 2 is attached to the wall by a string, so it won't simply move with the block 1.

Please find the free body diagrams in the figure provided below.

The equilibrium condition for the mass 1 is

$\displaystyle F_a-F_{r1}-F_{r2}=m.a=0$

The mass m1 is being pushed by the force Fa so that slipping with the mass m2 barely occurs, thus the system is not moving, and a=0. Solving for Fa

$\displaystyle F_a=F_{r1}+F_{r2}.....[1]$

The mass 2 is tried to be pushed to the right by the friction force Fr2 between them, but the string keeps it fixed in position with the tension T. The equation in the horizontal axis is

$\displaystyle F_{r2}-T=0$

The friction forces are computed by

$\displaystyle F_{r2}=\mu \ N_2=\mu\ m_2\ g$

$\displaystyle F_{r1}=\mu \ N_1=\mu(m_1+m_2)g$

Recall N1 is the reaction of the surface on mass m1 which holds a total mass of m1+m2.

Replacing in [1]

$\displaystyle F_{a}=\mu \ m_2\ g\ +\mu(m_1+m_2)g$

Simplifying

$\displaystyle F_{a}=\mu \ g(m_1+2\ m_2)$

Plugging in the values

$\displaystyle F_{a}=0.25(9.8)[400+2(100)]$

$\boxed{F_a=1470\ N}$

8 0

2 years ago

The angle θ is slowly increased. Write an expression for the angle at which the block begins to move in terms of μs.

Reika [66]

Answer:

$tan \theta = \mu_s$

Explanation:

An object is at rest along a slope if the net force acting on it is zero. The equation of the forces along the direction parallel to the slope is:

$mg sin \theta - \mu_s R =0$ (1)

where

$mg sin \theta$ is the component of the weight parallel to the slope, with m being the mass of the object, g the acceleration of gravity, $\theta$ the angle of the slope

$\mu_s R$ is the frictional force, with $\mu_s$ being the coefficient of friction and R the normal reaction of the incline

The equation of the forces along the direction perpendicular to the slope is

$R-mg cos \theta = 0$

where

R is the normal reaction

$mg cos \theta$ is the component of the weight perpendicular to the slope

Solving for R,

$R=mg cos \theta$

And substituting into (1)

$mg sin \theta - \mu_s mg cos \theta = 0$

Re-arranging the equation,

$sin \theta = \mu_s cos \theta\\\rightarrow tan \theta = \mu_s$

This the condition at which the equilibrium holds: when the tangent of the angle becomes larger than the value of $\mu_s$ , the force of friction is no longer able to balance the component of the weight parallel to the slope, and so the object starts sliding down.

4 0

2 years ago

A guitar string has a linear density of 8.30 ✕ 10−4 kg/m and a length of 0.660 m. the tension in the string is 56.7 n. when the

Sedbober [7]

Ans: Beat Frequency = 1.97Hz

Explanation:
The fundamental frequency on a vibrating string is

$f = \sqrt{ \frac{T}{4mL} }$ <span> -- (A)</span>

<span>here, T=Tension in the string=56.7N,
L=Length of the string=0.66m,
m= mass = 8.3x10^-4kg/m * 0.66m = 5.48x10^-4kg </span>

Plug in the values in Equation (A)

<span>so </span> $f = \sqrt{ \frac{56.7}{4*5.48*10^{-4}*0.66} }$ <span> = 197.97Hz </span>

<span>the beat frequency is the difference between these two frequencies, therefore:
Beat frequency = 197.97 - 196.0 = 1.97Hz
-i</span>

3 0

2 years ago

Read 2 more answers

If there is a potential difference v between the metal and the detector, what is the minimum energy emin that an electron must h

beks73 [17]

The electrical potential energy of a charge q located at a point at potential V is given by
$U=qV$
Therefore, if the charge must move between two points at potential V1 and V2, the difference in potential energy of the charge will be
$\Delta U = q (V_2 -V_1)=q \Delta V$

In our problem, the electron (charge e) must travel across a potential difference V. So the energy it will lose traveling from the metal to the detector will be equal to
$\Delta U = e V$
Therefore, if we want the electron to reach the detector, the minimum energy the electron must have is exactly equal to the energy it loses moving from the metal to the detector:
$E_{min} = \Delta U = eV$

5 0
