Answer:
long duct: 1.0 and 0.424
Hemisphere 1.0 ; 0.125; 0.5
Explanation:
For a long duct:
By inspection,
Calculating by reciprocity,
Hemisphere:
By reciprocity gives = 0.125
using the summation rule:
However, because this is a hemisphere, the value will be= 0.5 * 1
= 0.5
Answer:
a)σ₁ = 265.2 MPa
b)σ₂ = -172.8 MPa
c)
d)Range = 438 MPa
Explanation:
Given that
Mean stress ,σm= 46.2 MPa
Stress amplitude ,σa= 219 MPa
Lets take
Maximum stress level = σ₁
Minimum stress level =σ₂
The mean stress given as
2 x 46.2 = σ₁ + σ₂
σ₁ + σ₂ = 92.4 MPa --------1
The amplitude stress given as
2 x 219 = σ₁ - σ₂
σ₁ - σ₂ = 438 MPa --------2
By adding the above equation
2 σ₁ = 530.4
σ₁ = 265.2 MPa
-σ₂ = 438 -265.2 MPa
σ₂ = -172.8 MPa
Stress ratio
Range = 265.2 MPa - ( -172.8 MPa)
Range = 438 MPa
Answer:
X_cp = c/2
Explanation:
We are given;
Chord = c
Angle of attack = α
p u (s) = c 1
p1(s)=c2,
and c2 > c1
First of all, we need to find the resultant normal force on the plate and the total moment about leading edge.
I've attached the solution
