Particles (mass of each = 0.40 kg) are placed at the 60-cm and 100-cm marks of a meter stick of negligible mass. This rigid body

is free to rotate about a frictionless pivot at the 0-cm end. The body is released from rest in the horizontal position. What is the magnitude of the initial linear acceleration of the end of the body opposite the pivot?

1 answer:

hichkok12 [17]2 years ago

7 0

Answer:

12 m/s ∧2

Explanation:

The picture attached explains it all and i hope it helps. Thank you

You might be interested in

While dangling a hairdryer by its cord, you observe that the cord is vertical when the hairdryer isoff and, once it is turned on

jekas [21]

Answer:

The speed of the air leaving the hairdryer is 10m/s.

Explanation:

The thrust that the dryer produces is what keeps it elevated at an angle of 5° from the vertical; therefore, from the force diagram we get

$(1).\: tan (5^o) = \dfrac{F_t}{Mg}$

putting in $M =0.420kg$ , $g = 9.8m/s^2$ and solving for $F_t$ we get:

$F_t = Mg\:tan(5^o)$

$F_t = (0.420kg)(9.8m/s^2)\:tan(5^o)$

$\boxed{F_t = 0.3601N.}$

Now, this thrust produced is related to to the air ejection speed $v$ by the relation

$(2).\: F_t = v\dfrac{dM}{dt}$

where $dM/dt$ is the rate of air ejection which we know is

$0.06m^3/2s = 0.03m^3/s$

and since $1m^3 = 1.2kg$ ,

$0.03m^3/s \rightarrow 0.036kg/s$

$\dfrac{dM}{dt} = 0.036kg/s,$

putting this into equation (2) and the value of $F_t$ we get:

$0.3601N = 0.036v$

which gives

$v= \dfrac{0.3601}{0.036}$

$\boxed{v =10m/s.}$

which is the speed of the air ejected.

6 0

2 years ago

In a harbor, you can see sea waves traveling around the edges of small stationary boats. Why does this happen?

faust18 [17]

Below are the choices that can be found in the other sources:

A. diffraction
<span>B. refraction </span>
<span>C. reflection </span>
<span>D. transmission
</span>
The answer is diffraction. It means that <span>the process by which a beam of light or other system of waves is spread out as a result of passing through a narrow aperture or across an edge, typically accompanied by interference between the wave forms produced.</span>

8 0

2 years ago

a stone is projected vertically up from the top of a tower 73.5m with velocity 24.5 m/s . find the time taken by the stone to re

hoa [83]

The stone's altitude at time $t$ is given by

$y=73.5\,\mathrm m+\left(24.5\dfrac{\rm m}{\rm s}\right)t-\dfrac g2t^2$

where $g=9.80\dfrac{\rm m}{\mathrm s^2}$ is the acceleration due to gravity. The stone reaches the ground when $y=0$ :

$0=73.5\,\mathrm m+\left(24.5\dfrac{\rm m}{\rm s}\right)t-\dfrac g2t^2\implies t=7.11\,\rm s$

6 0

2 years ago

Differences between Pressure and upthrust

Angelina_Jolie [31]

Answer:

Pressure is equal to the ratio of thrust to the area in contact. Upthrust is a force exerted by the fluids on an object placed in the fluid . Upthrust acts in upward direction.

4 0

2 years ago

a child hits a ball with a force of 350 N. (a) If the ball and bat are in contact for 0.12 is, what impulse does the ball receiv

Lina20 [59]

Explanation:

Given that,

Force with which a child hits a ball is 350 N

Time of contact is 0.12 s

We need to find the impulse received by the ball. The impulse delivered is given by :

$J=F\times t\\\\J=350\times 0.12\\\\J=42\ N-m$

So, the impulse is 42 N-m..

We know that he change in momentum is also equal to the impulse delivered.

So, impulse = 42 N-m and change in momentum =42 N-m.

7 0
