The transfer of energy through varios stages in an ecological community is called

Two resistors of 5.0 and 9.0 ohm are connected in parallel. A 4.0 ohm resistor is then connected in series with the parallel com

rewona [7]

Answer:

I1 = 0.772 A

Explanation:

Given: R1 = 5.0 ohm, R2 = 9.0 ohm, R3 = 4.0 ohm, V = 6.0 Volts

To find: current I = ? A

Solution:

Ohm's law V= I R

⇒ I = V / R

In order to find R (total) we first find R (p) fro parallel combination. so

1 / R (p) = 1 / R1 + 1/ R2 ∴(P) stand for parallel

R (p) = R1R2 / ( R1 + R2)

R (p) = (5.0 × 9.0) / (5.0 + 9.0)

R (p) = 3.214 ohm

Now R (total) = R (p) + R3 (as R3 is connected in series)

R (total) = 3.214 ohm + 4.0 Ohm

R (total) = 7.214 ohm

now I (total) = 7.214 ohm / 6.0 Volts

I (total) = 1.202 A

This the total current supplied by 6 volts battery.

as voltage drop across R (p) = V = R (p) × I (total)

V (p) = 3.214 ohm × 1.202 A = 3.864 volts

Now current through 5 ohms resister is I1 = V (P) / R1

I1 = 3.864 volts / 5 ohm

I1 = 0.772 A

3 0

2 years ago

Astronomers have discovered a new planet called "Xandar" beyond the orbit of Pluto (No, not really but I need a fake planet for

Burka [1]

Answer:

m = 1.82E+23 kg

Explanation:

G = universal gravitational constant = 6.67E-11 N·m²/kg²

r = radius of orbit = 72,600 km = 7.26E+07 m

C = circumference of orbit = 2πr = 4.56E+08 m

P = period of orbit = 12.9 d = 1,114,560 s

v = orbital velocity of satellite Jim = C/P = 409 m/s

m = mass of Xandar = to be determined

v = √(Gm/r)

v² = [√(Gm/r)]²

v² = Gm/r

rv² = Gm

rv²/G = m

m = rv²/G

mG = universal gravitational constant = 6.67E-11 N·m²/kg²

r = radius of orbit = 72,600 km = 7.26E+07 m

C = circumference of orbit = 2πr = 4.56E+08 m

P = period of orbit = 12.9 d = 1,114,560 s

v = orbital velocity of satellite Jim = C/P = 409 m/s

m = mass of Xandar = to be determined

v = √(Gm/r)

v² = [√(Gm/r)]²

v² = Gm/r

rv² = Gm

rv²/G = m

m = rv²/G

m = 1.82E+23 kg

3 0

2 years ago

Joe learned that decaying plants produce an acidic environment. Joe wants to know if pill bugs prefer acidic environments instea

Anna11 [10]

Yessgshhshe the answer

6 0

2 years ago

Read 2 more answers

Imagine you derive the following expression by analyzing the physics of a particular system: M= (mv2r)(mGr2). Simplify the expre

alex41 [277]

Answer:

The simplified expression is $M = \frac{v^2 r}{G}$

Explanation:

From the question we are told that

$M = \frac{ \frac{m v^2}{r} }{\frac{ mG}{r^2 } }$

So simplifying we have

$M = \frac{m v^2}{r} * \frac{r^2 }{ mG }$

$M = \frac{v^2 r}{G}$

Thus the simplified formula is $M = \frac{v^2 r}{G}$

3 0

2 years ago

To crossing over the flooded canal.

zubka84 [21]

Answer:

F. jumping

Explanation:

you can't throw/toss yourself, you cant roll over water, catching?, you cant run over water, jumps are bigger than hops

4 0

2 years ago
