abin is doing work by lifting a bowling ball. Which statement could be made about the energy in this situation?

2 answers:

8 0

The statement that could be made about the energy in this situation would be :
It being transferred from his arms muscles to the ball.

The muscle contraction from his arms created a force that could be used to lift the ball up.<span />

bekas [8.4K]2 years ago

3 0

Answer:

Explanation:

You might be interested in

While it’s impossible to design a perpetual motion machine, that is, a machine that keeps moving forever, come up with ways to k

MissTica

A perpetual motion machine is (as the name implies) a machine that moves perpetually; it never stops. Ever. So if you created one today and set it going, it would keep on going until the Big Freeze<span>. Calling that “a long time” is an understatement of epic proportions</span>

7 0

2 years ago

Read 2 more answers

1. Determina el momento que produce una fuerza de 7 N tangente a una rueda de un metro de diámetro, sabiendo que el punto de apl

Rudik [331]

Answer:

τ= F r into the blade

Explanation:

The moment of a force is defined by

τ = F x r

where the bold indicates vectors

Let us write in the expression in magnitude

τ = F r sin θ

in our case the force is tangent to the wheel therefore the angle between F and the radius is 90º, and the sin 90 = 1

τ= F r

The direction of τ can be used by the rule of the right hand, the fingers curve in the direction of the torque when advancing from the force to the radius and the thumb points in the direction of the torque.

In this case, for a clockwise rotation, the fingers are curved in the direction and the thumb points into the blade, this is the direction of the τ.

TRASLATE

El momento de una fura es definido por

τ = F x r

donde la negrillas indican vectores

Escribamos en ta expresión en magnitud

τ = F r sin θ

en nuestro caso la fuerza es tangente a la rueda por lo tanto el angulo entre F y el radios es 90º, y el sin 90=1

τ = F r

la dirección de tau la podemos usar la regla de la mano derecha, los dedos curva en la dirección del torque al avanzar dese la fuerza al radio y el pulgar apunta en la dirección del torque.

En este caso para un giro en sentido horario los dedos se curvan ente sentido y el pulgar apunta hacia dentro de lla hoja, esta es la dirección del troque

5 0

2 years ago

8. The resistance of a bagel toaster is 14 Ω. To prepare a bagel, the toaster is operated for one minute from a 120-V outlet. Ho

IgorC [24]

Answer: The energy delivered to the toaster is 264.490KJ

Explanation:

Here is the complete question:

The resistance of a bagel toaster is 14 ?. To prepare a bagel, the toaster is operated for one minute from a 120-V outlet. How much energy is delivered to the toaster?

Step-by-step explanation:

Please see attachment below

7 0

2 years ago

Read 2 more answers

A shot putter releases the shot some distance above the level ground with a velocity of 12.0 m/s, 51.0 ∘above the horizontal. Th

alina1380 [7]

A) Zero

The motion of the shot is a projectile's motion: this means that there is only one force acting on the projectile, which is gravity. However, gravity only acts in the vertical direction: so, there are no forces acting in the horizontal direction. Therefore, the x-component of the acceleration is zero.

B) -9.8 m/s^2

The vertical acceleration is given by the only force acting in the vertical direction, which is gravity:

$F=mg$

where m is the projectile's mass and g is the gravitational acceleration. Therefore, the y-component of the shot's acceleration is equal to the acceleration due to gravity:

$a_y = g = -9.8 m/s^2$

where the negative sign means it points downward.

C) 7.6 m/s

The x-component of the shot's velocity is given by:

$v_x = v_0 cos \theta$

where

$v_0 = 12.0 m/s$ is the initial velocity

$\theta=51.0^{\circ}$ is the angle of the shot

Substituting into the equation, we find

$v_x = (12.0 m/s)(cos 51^{\circ})=7.6 m/s$

D) 9.3 m/s

The y-component of the shot's velocity is given by:

$v_y = v_0 sin \theta$

where

$v_0 = 12.0 m/s$ is the initial velocity

$\theta=51.0^{\circ}$ is the angle of the shot

Substituting into the equation, we find

$v_y = (12.0 m/s)(sin 51^{\circ})=9.3 m/s$

E) 7.6 m/s

We said at point A) that the acceleration along the x-direction is zero: therefore, the velocity along the x-direction does not change, so the x-component of the velocity at the end of the trajectory is equal to the x-velocity at the beginning:

$v_x = 7.6 m/s$

F) -11.1 m/s

The y-component of the velocity at time t is given by:

$v_y(t) = v_y + at$

where

$v_y = 9.3 m/s$ is the initial y-velocity

a = g = -9.8 m/s^2 is the vertical acceleration

t is the time

Since the total time of the motion is t=2.08 s, we can substitute this value into the equation, and we find:

$v_y(2.08 s)=9.3 m/s + (-9.8 m/s^2)(2.08 s)=-11.1 m/s$

where the negative sign means the vertical velocity is now downward.

3 0

2 years ago

An electric air heater consists of a horizontal array of thin metal strips that are each 10 mm long in the direction of an airst

sweet-ann [11.9K]

Answer:

see explanation below

Explanation:

Given that,

$T_1 =$ 500°C

$T_2$ = 25°C

d = 0.2m

L = 10mm = 0.01m

U₀ = 2m/s

Calculate average temperature

$\\T_{avg} = \frac{T_1 + T_2}{2} \\\\T_{avg} = \frac{500 + 25}{2} \\\\T_{avg} = 262.5$

262.5 + 273

= 535.5K

From properties of air table A-4 corresponding to $T_{avg}$ = 535.5K $\approx 550K$

k = 43.9 × 10⁻³W/m.k

v = 47.57 × 10⁻⁶ m²/s

$P_r = 0.63$

Number for the first strips is equal to

$R_e_x = \frac{u_o.L}{v}$

$R_e_x = \frac{2\times 0.01}{47.57 \times 10^-^6 }\\\\= 420.4$

Calculating heat transfer coefficient from the first strip

$h_1 = \frac{k}{L} \times 0.664 \times R_e_x^1^/^2 \times P_r^1^/^3$

$h_1 = \frac{43.9 \times 10^-^3}{0.01} \times 0.664\times420 \times 4^1^/^2 \times 0.683^1^/^3\\\\= 52.6W/km^2$

The rate of convection heat transfer from the first strip is

$q_1 = h_1\times(L\times d)\times(T_1 - T_2)\\\\q_1 = 52.6 \times (0.01\times0.2)\times(500-25)\\\\q_1 = 50W$

The rate of convection heat transfer from the fifth trip is equal to

$q_5 = (5 \times h_o_-_5-4\times h_o_-_4) \times(L\times d)\times (T_1 -T_2)$

$h_o_-_5 = \frac{k}{5L} \times 0.664 \times (\frac{u_o\times 5L}{v} )^1^/^2\times Pr^1^/^3\\\\= \frac{43.9\times10^-^3}{0.05} \times0.664\times (\frac{2 \times 0.05}{47.57 \times 10^-^6} )^1^/^2\times 0.683^1^/^3\\\\= 25.5W/Km^2$

Calculating $h_o_-_4$

$h_o_-_4 = \frac{k}{4L} \times 0.664 \times (\frac{u_o\times 4L}{v } )^1^/^2\times Pr^1^/^3\\\\= \frac{43.9\times10^-^3}{0.04} \times0.664\times (\frac{2 \times 0.04}{47.57 \times 10^-^6} )^1^/^2\times 0.683^1^/^3\\\\= 26.3W/Km^2$

The rate of convection heat transfer from the tenth strip is

$q_1_0 = (10 \times h_o_-_1_0-9\times h_o_-_9) \times(L\times d)\times (T_1 -T_2)$

$h_o_-_1_0 = \frac{k}{10L} \times 0.664 \times (\frac{u_o\times 10L}{v } )^1^/^2\times Pr^1^/^3\\\\= \frac{43.9\times10^-^3}{0.1} \times0.664\times (\frac{2 \times 0.1}{47.57 \times 10^-^6} )^1^/^2\times 0.683^1^/^3\\\\= 16.6W/Km^2$

Calculating

$h_o_-_9 = \frac{k}{9L} \times 0.664 \times (\frac{u_o\times 9L}{v } )^1^/^2\times Pr^1^/^3\\\\= \frac{43.9\times10^-^3}{0.09} \times0.664\times (\frac{2 \times 0.09}{47.57 \times 10^-^6} )^1^/^2\times 0.683^1^/^3\\\\= 17.5W/Km^2$

Calculating the rate of convection heat transfer from the tenth strip

$q_1_0 = (10 \times h_o_-_1_0-9\times h_o_-_9) \times(L\times d)\times (T_1 -T_2)\\\\q_1_0 = (10 \times 16.6 -9\times 17.5) \times(0.01\times 0.2)\times (500 -25)\\\\=8.1W$

The rate of convection heat transfer from 25th strip is equal to

$q_2_5 = (25 \times h_o_-_2_5-24\times h_o_-_2_4) \times(L\times d)\times (T_1 -T_2)$

Calculating $h_o_-_2_5$

$h_o_-_2_5 = \frac{k}{25L} \times 0.664 \times (\frac{u_o\times 25L}{v } )^1^/^2\times Pr^1^/^3\\\\= \frac{43.9\times10^-^3}{0.25} \times0.664\times (\frac{2 \times 0.25}{47.57 \times 10^-^6} )^1^/^2\times 0.683^1^/^3\\\\= 10.5W/Km^2$

Calculating $h_o_-_2_4$

$h_o_-_2_4 = \frac{k}{24L} \times 0.664 \times (\frac{u_o\times 24L}{v } )^1^/^2\times Pr^1^/^3\\\\= \frac{43.9\times10^-^3}{0.24} \times0.664\times (\frac{2 \times 0.24}{47.57 \times 10^-^6} )^1^/^2\times 0.683^1^/^3\\\\= 10.7W/Km^2$

Calculating the rate of convection heat transfer from the tenth strip

$q_2_5 = (25 \times h_o_-_2_5-24\times h_o_-_2_4) \times(L\times d)\times (T_1 -T_2)\\\\q_1_0 = (25 \times 10.5 -24\times 10.7) \times(0.01\times 0.2)\times (500 -25)\\\\=5.4W$

6 0

2 years ago
