A water wave traveling in a straight line on a lake is described by the equation:y(x,t)=(2.75cm)cos(0.410rad/cm x+6.20rad/s t)Wh

ere y is the displacement perpendicular to the undisturbed surface of the lake. a. How much time does it take for one complete wave pattern to go past a fisherman in a boat at anchor, and what horizontal distance does the wave crest travel in that time? b. What are the wave number and the number of waves per second that pass the fisherman? c. How fast does a wave crest travel past the fisherman, and what is the maximum speed of his cork floater as the wave causes it to bob up and down?

1 answer:

Georgia [21]2 years ago

6 0

Answer:

A) The wave equation is defined as

$y(x,t) = A\cos(kx + \omega t)=0.0275\cos(0.0041x + 6.2t)\\$

Using the wave equation we can deduce the wave number and the angular velocity. k = 0.0041 and ω = 6.2.

The time it takes for one complete wave pattern to go past a fisherman is period.

$\omega = 2\pi f\\ f = 1/ T$

T = 1.01 s.

The horizontal distance the wave crest traveled in one period is

$\lambda = 2\pi / k = 2\pi / 0.0041 = 1.53\times 10^3~m$

$y(x = \lambda,t = T) = 0.0275\cos(0.0041*1.53*\10^3 + 6.2*1.01) = 0.0275~m$

B) The wave number, k = 0.0041 . The number of waves per second is the frequency, so f = 0.987.

C) A wave crest travels past the fisherman with the following speed

$v = \lambda f = 1.53\times 10^3 * 0.987 = 1.51\times 10^3~m/s$

The maximum speed of the cork floater can be calculated as follows.

The velocity of the wave crest is the derivative of the position with respect to time.

$v(x,t) = \frac{dy(x,t)}{dt} = -(6.2\times 0.0275)\sin(0.0041x + 6.2t)$

The maximum velocity can be found by setting the derivative of the velocity to zero.

$\frac{dv_y(x,t)}{dt} = -(6.2)^2(0.0275)\cos(0.0041*1.53\times 10^3 + 6.2t) = 0$

In order this to be zero, cosine term must be equal to zero.

$0.0041*1.53\times 10^3 + 6.2t = 5\pi /2\\t = 0.255~s$

The reason that cosine term is set to be 5π/2 is that time cannot be zero. For π/2 and 3π/2, t<0.

$v(x=\lambda, t = 0.255) = -(6.2\times0.0275)\sin(0.0041\times 1.53\times 10^3 + 6.2\times 0.255) = -0.17~m/s$

You might be interested in

Evaporation of sweat requires energy and thus take excess heat away from the body. Some of the water that you drink may eventual

kotegsom [21]

Answer:

The amount of heat required is $H_t = 1.37 *10^{6} \ J$

Explanation:

From the question we are told that

The mass of water is $m_w = 20 \ ounce = 20 * 28.3495 = 5.7 *10^2 g$

The temperature of the water before drinking is $T_w = 3.8 ^oC$

The temperature of the body is $T_b = 36.6^oC$

Generally the amount of heat required to move the water from its former temperature to the body temperature is

$H= m_w * c_w * \Delta T$

Here $c_w$ is the specific heat of water with value $c_w = 4.18 J/g^oC$

So

$H= 5.7 *10^2 * 4.18 * (36.6 - 3.8)$

=> $H= 7.8 *10^{4} \ J$

Generally the no of mole of sweat present mass of water is

$n = \frac{m_w}{Z_s}$

Here $Z_w$ is the molar mass of sweat with value

$Z_w = 18.015 g/mol$

=> $n = \frac{5.7 *10^2}{18.015}$

=> $n = 31.6 \ moles$

Generally the heat required to vaporize the number of moles of the sweat is mathematically represented as

$H_v = n * L_v$

Here $L_v$ is the latent heat of vaporization with value $L_v = 7 *10^{3} J/mol$

=> $H_v = 31.6 * 7 *10^{3}$

=> $H_v = 1.29 *10^{6} \ J$

Generally the overall amount of heat energy required is

$H_t = H + H_v$

=> $H_t = 7.8 *10^{4} + 1.29 *10^{6}$

=> $H_t = 1.37 *10^{6} \ J$

4 0

2 years ago

A heavy stone of mass m is hung from the ceiling by a thin 8.25-g wire that is 65.0 cm long. When you gently pluck the upper end

Triss [41]

Answer: m= 35.6 kg

Explanation:

For finding the mass of the stone we have the formula

v= $\sqrt{\frac{Tension}{Linear. Mass. density} }$

Here, Tension= m*g = m*9.81

and linear mass density= $\frac{8.25 g}{65 cm}$

Linear mass density= $\frac{8.25*10^-3}{65*10^-2}$

Linear mass density= 0.0127 kg/m

Velocity= $2*\frac{l}{t}$

Velocity= 2 * $\frac{65*10^-2}{7.84}$

Velocity= 165.8 m/s

So putting all these values in equation we get

v= $\sqrt{\frac{Tension}{Linear. Mass. density} }$

165.8= $\sqrt{\frac{m*9.81}{0.0127} }$

Solving we get

m= 35.58 kg

or m= 35.6 kg

3 0

2 years ago

B. A hydraulic jack has a ram of 20 cm diameter and a plunger of 3 cm diameter. It is used for lifting a weight of 3 tons. Find

lozanna [386]

Answer:

option (b)

Explanation:

According to the Pascal's law

F / A = f / a

Where, F is the force on ram, A be the area of ram, f be the force on plunger and a be the area of plunger.

Diameter of ram, D = 20 cm, R = 20 / 2 = 10 cm

A = π R^2 = π x 100 cm^2

F = 3 tons = 3000 kgf

diameter of plunger, d = 3 cm, r = 1.5 cm

a = π x 2.25 cm^2

Use Pascal's law

3000 / π x 100 = f / π x 2.25

f = 67.5 Kgf

4 0

1 year ago

When a car drives along a "washboard" road, the regular bumps cause the wheels to oscillate on the springs. (What actually oscil

marishachu [46]

Answer:

a) 40,000 N/m

b) f = 6.37 Hz

c) v = 4,8 m/s

Explanation:

part a)

First in order to estimate the spring constant k, we need to know the expression or formula to use in this case:

k = ΔF / Δx

Where:

ΔF: force that the men puts in the car, in this case, the weight.

Δx: the sinking of the car, which is 2 cm or 0.02 m.

With this data, and knowing that there are four mens, replace the data in the above formula:

W = 80 * 10 = 800 N

This is the weight for 1 man, so the 4 men together would be:

W = 800 * 4 = 3200 N

So, replacing this data in the formula:

k = 3200 / 0.02 = 160,000 N/m

This means that one spring will be:

k' = 160,000 / 4 = 40,000 N/m

b) An axle and two wheels has a mass of 50 kg, so we can assume they have a parallel connection to the car. If this is true, then:

k^n = 2k

To get the frequency, we need to know the angular speed of the car with the following expression:

wo = √k^n / M

M: mass of the wheel and axle, which is 50 kg

k = 40,000 N/m

Replacing the data:

wo = √2 * 40,000 / 50 = 40 rad/s

And the frequency:

f = wo/2π

f = 40 / 2π = 6.37 Hz

c) finally for the speed, we have the time and the distance, so:

V = x * t

The only way to hit bumps at this frequency, is covering the gaps of bumping, about 6 times per second so:

x: distance of 80 cm or 0.8 m

V = 0.8 * 6 =

V = 4.8 m/s

5 0

2 years ago

Water flows without friction vertically downward through a pipe and enters a section where the cross sectional area is larger. T

djverab [1.8K]

Answer:

$v_{2}$ will be less than $v_{1}$ and $P_{2}$ will be greater than $P_{1}$ .

Explanation:

As we know from the conservation of mass, the rate at which any amount of fluid mass ( $m_{1}$ ) is entering in a system is equal to the rate at which the same amount of fluid mass ( $m_{2}$ ) is leaving the system.

Rate of mass flow can be written as,

$m = \rho A v$

where $\rho$ is the density of the fluid, $A$ is the area through which the fluid is flowing and $v$ is the velocity of the fluid.

Now, according to the problem, as the density of the fluid does not change, we can write

$&& m_{1} = m_{2}\\&or,& \rho A_{1} v_{1} = \rho A_{2} v_{2}\\&or,& \dfrac{v_{2}}{v_{1}} = \dfrac{A_{1}}{A_{2}}$

where $A_{1}$ and $A_{2}$ are the cross-sectional areas through which the fluid is passing and $v_{1}$ and $v_{2}$ are the velocities of the fluid through the respective cross-sectional areas.

As according to the problem, $A_{2} > A_{1}$ , so from the above formula $v_{2} < v_{1}$ .

Also we know that fluid pressure is created by the motion of the fluid through any area. When the fluid gains speed, some of its energy is used to move faster in the fluid’s direction of motion. It causes in a lower pressure.

So, as in this case $v_{2} < v_{1}$ the pressure in the large cross-sectional area $P_{2}$ will be greater than the pressure $P_{1}$ in the small cross sectional area, i.e.,

$P_{2} > P_{1}$ .

6 0
